Custom Minimalist Mailer (CMM4)

A lightweight, sandboxed WordPress form-builder and SMTP mail engine — built around a self-contained, fault-isolated addon architecture.

Originally engineered for the ALK (Alkhidmat) Elementor theme, CMM4 replaces generic form-plugin bloat with a single, auditable core file plus small, hot-pluggable addons. No external PHP libraries, no Composer dependencies — just WordPress core functions, talking directly to third-party APIs over HTTP.

Built With

Table of Contents

• Overview
• Key Features
• Supported Field Types
• Bundled Addons
• Architecture
• Installation
• Quick Start
• Field Syntax Reference
• Shortcode Reference
• Admin Menu Guide
• Security
• File Uploads & Data Export
• Building Your Own Addon
• Requirements
• Project Structure
• Component Versions
• License
• Author

Overview

CMM4 turns any WordPress page into a fully configurable form — contact forms, job applications, inquiry forms — rendered through a single shortcode, routed through your own SMTP server, and logged to a dedicated database table. Every field (layout, validation, labels, options) is defined in one simple text block per form, no page-builder lock-in required.

On top of that core, an addon system lets specific features (Google Sheets sync, location-based eligibility rules, a visual field builder) live in their own self-contained files — each one optional, independently versioned, and isolated so that a bug in one addon can never take down the rest of the site.

Key Features

Supported Field Types

Fields are defined per form in a simple pipe-delimited syntax (see Field Syntax Reference). Supported type values:

Addons can also register entirely new field types via the cmm4_render_custom_field filter, without touching the core file.

Bundled Addons

1. In Google Cloud Console, create a project and enable the Google Sheets API and Google Drive API.
2. Go to APIs & Services → Credentials → Create Credentials → OAuth client ID. Application type: Web application.
3. Under Authorized redirect URIs, add the URL shown on CMM Forms → Job Application Sync (looks like https://yoursite.com/wp-admin/admin.php?page=cmm4-job-app-sync).
4. Copy the Client ID and Client Secret into the addon's settings page and save.
5. Click Connect with Google and approve access using the account that owns your target Sheet and Drive folder.
6. Fill in the Spreadsheet ID (from the sheet's URL, between /d/ and /edit), the Drive Folder ID (from the folder's URL, after /folders/), and the Job Application Form ID(s) to watch.
7. Enable Sync, save, then use Send Test Row to confirm the Sheet and Drive folder are both reachable before relying on it for real applications.

Until the OAuth app is submitted for Google's verification review, the consent screen shows an "unverified app" warning — normal for single-user apps. Click Advanced → Go to (app name) (unsafe) to proceed.

1. Go to CMM Forms → Application Guard.
2. Enter the Job Application Form ID(s) this should apply to (comma-separated for multiple).
3. Turn on the rules you want — duplicate blocking, and/or up to three independent location rules.
4. For each location rule, make sure the form has a matching field. A dropdown field type is recommended so applicants can only pick from your list — the rule is then re-checked server-side regardless, so tampering with submitted data can't bypass it.

Architecture

flowchart LR
    A[Visitor submits form] --> B{Nonce valid?}
    B -- no --> X[Rejected]
    B -- yes --> C{reCAPTCHA v3 check}
    C -- fail --> X
    C -- pass --> D["cmm4_validate_submission filter<br/>(addons can block here)"]
    D -- blocked --> X
    D -- ok --> E[File upload processed<br/>+ submission saved to DB]
    E --> F["cmm4_after_submission_saved action<br/>(addons sync here)"]
    F --> G[Notification email + Autoreply sent]

Core building blocks:

• A hidden custom post type, cmm4_form, stores each form's configuration as post meta.
• A dedicated table, {wp_prefix}cmm4_submissions, stores every submission (created on activation, re-checked on init).
• The shortcode render engine (cmm4_shortcode_render) turns a form's field list into responsive HTML on the fly.
• The addon loader scans /addons/{slug}/{slug}.php automatically — no registration step, no edits to the core file. Addons can be toggled individually from CMM Forms → Addons, and a fatal error in one addon is caught and logged without affecting the rest of the site.

Installation

1. Upload the custom-mailer-v6-geo folder to /wp-content/plugins/, or install the ZIP via Plugins → Add New → Upload Plugin.
2. Activate Custom Minimalist Mailer (CMM4) from the Plugins screen.
3. Go to CMM Forms → SMTP Gateway and enter your mail server's host, port, encryption type, and credentials.
4. (Optional) Visit CMM Forms → Addons to enable Pakistan Location Dropdowns, Job Application Sync, Application Guard, or Visual Field Editor.
5. Create your first form from the CMM Forms dashboard.

Quick Start

1. CMM Forms → Add New Form, define the fields using the pipe syntax below (or the Visual Field Editor, if enabled).
2. Copy the form's ID from the dashboard list.
3. Drop the shortcode onto any page or post:

[cmm4_form id="123"]

Field Syntax Reference

Each line in a form's field list defines one field:

Label|type|required|placeholder|css_class|options

Example field list:

First Name|text|required|||
Phone Number|tel||+92 300 0000000||
Project Details|textarea|required|Tell us about your project...||
Budget Range|select|required|||Under $1k, $1k - $5k, $5k+
I agree to the privacy policy|checkbox|required|||
Services Required|checkbox||||Apparel Sourcing, Brand Design, Logistics
Street Address|text|required||full-row|
Resume|file|required|||pdf, doc, docx
Department|acf_locked|required||full-row|department
Available Positions|acf_dropdown|required||full-row|positions
Skills You Have|acf_checkbox|||full-row|skills
Shift Preference|acf_radio|required|||shift_options
Gender|radio|||full-row|Male, Female, Other
District|select|required|||Ghotki, Mirpur Mathelo, Daharki, Ubaro
Province|select|required|||Sindh, Punjab, KPK, Balochistan

Shortcode Reference

[cmm4_form id="2659"]
[cmm4_form id="2659" cols="2"]
[cmm4_form id="2659" cols="3" labels="no"]
[cmm4_form id="2659" cols="1" label_position="left"]

Admin Menu Guide

All screens live under CMM Forms in the WordPress admin sidebar:

Security

• Nonce verification on every form submission, tied to the specific form ID.
• reCAPTCHA v3, loaded only on pages that actually contain a [cmm4_form] shortcode — never site-wide.
• Private file storage: uploads live outside the public media library, in a folder blocked by .htaccess, with randomized filenames. Downloads require an admin login and a valid HMAC signature derived from the site's own AUTH_KEY/AUTH_SALT — links can't be forged or guessed.
• Addon fault isolation: a fatal error in one addon is caught and logged per-request; it cannot crash the core plugin or other addons.
• Version gating: an addon that declares Requires CMM4 at least is skipped (with a clear admin-visible reason) if the running core version is older — never silently fails with a fatal error.
• CSV injection protection: exported values are prefixed to prevent spreadsheet apps from treating submitted data as a formula.

File Uploads & Data Export

• Uploads are validated against a configurable extension allow-list (default pdf, doc, docx), capped at 5MB, and stored outside the public upload directory.
• CSV export is available per-form, including a one-click download of a single submission's data.
• Bulk ZIP export packages every application for a form and every attached resume file into one archive — nonce-protected so it can't be triggered by a crafted URL.

Building Your Own Addon

Drop a new folder into /addons/{your-addon-slug}/{your-addon-slug}.php — it's picked up automatically on the next page load, no core file edits needed.

<?php
/**
 * Addon Name: My Addon
 * Description: One line describing what it does.
 * Version: 1.0.0
 * Author: Your Name
 * Requires CMM4 at least: 6.10.0
 */

if ( ! defined( 'ABSPATH' ) ) {
    exit;
}

// Your addon logic, hooked into one or more of the points below.

All header fields are optional — an addon with no header still loads, showing its folder name on the Addons screen instead of a friendly name.

Available hook points:

Requirements

• A standard WordPress installation — CMM4 uses only WordPress core functions, with no external PHP libraries or Composer dependencies.
• MySQL / MariaDB (via $wpdb, WordPress's own database layer).
• Job Application Sync addon: a Google Cloud project with the Sheets and Drive APIs enabled, plus an OAuth 2.0 Client ID/Secret (free tier is sufficient).
• Security Shield: a Google reCAPTCHA v3 site/secret key pair (optional).
• ACF field types (acf_locked, acf_dropdown, acf_checkbox, acf_radio) require Advanced Custom Fields to be active on fields tied to the relevant post type.

Project Structure

custom-mailer-v6-geo/
├── custom-mailer-v6.php              # Core plugin: CPT, admin UI, render engine, submission router
├── uninstall.php                     # Cleanup on delete (respects the Data Retention setting)
└── addons/
    ├── geo-locations/
    │   ├── geo-locations.php         # Pakistan Location Dropdowns
    │   └── geo-data.php              # Province > District > City dataset
    ├── job-application-sync/
    │   ├── job-application-sync.php  # Google Sheets & Drive sync (OAuth 2.0)
    │   └── uninstall.php
    ├── application-guard/
    │   ├── application-guard.php     # Duplicate-blocking & location eligibility rules
    │   └── uninstall.php
    └── visual-field-editor/
        └── visual-field-editor.php   # Click-based field builder UI

Component Versions

License

No license file is bundled with this repository. This plugin was built as a custom, site-specific tool; if you intend to distribute or open-source it, add a LICENSE file (MIT is a common, permissive choice for WordPress plugins) before publishing.

Author

Amanullah Khan

Developer & Maintainer — Web Development, Front-End Engineering & Social Media Management 📍 Pakistan
